1. Electric or steam heated.
2. Panel and drum adopt high quality stainless steel, acid and alkali resistance, anti-corrosion, good appearance, long life.
3. With mechanical suspension shock structure, low noise, free standing.
4. Adopted imported seal, sealing is good, no leakage.
5. Fully programmable electronic control, fault indication system.
6, Electrically operated Drain Valve.
All information is subject to change without notice.
Model | ST-12 | ST-15 | ST-22 | ST-25 | |
Drum Dimension | mm | Φ580x390 | Φ670x475 | Φ720x545 | Φ800x545 |
Drum Voluem | l | 103 | 167 | 221 | 274 |
Drum Speed | r/min | 52/700 | 40/850 | 46/800 | 46/750 |
Motor Power | kw | 1.5 | 1.5 | 2.2 | 3 |
Inverter Power | kw | 1.5 | 1.5 | 2.2 | 3.7 |
Dimension ( L*W*H) | mm | 1100x1000x1500 | 1100x1000x1500 | 1150x1060x1550 | 1120x1100x1600 |
Net Weight | kg | 480 | 520 | 580 | 700 |
